5-axis slide rail set 120 mm wide, 300 mm with 5-axis body

5-axis slide rail set 120 mm wide, 300 mm with 5-axis body
5-axis slide rail set 120 mm wide, 300 mm with 5-axis body 5-axis slide rail set 120 mm wide, 300 mm with 5-axis body 5-axis slide rail set 120 mm wide, 300 mm with 5-axis body
Price:
3.059,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
5-axis slide rail set 120 mm
  • For stable, low-vibration machining
  • 40 kN clamping force at 85 Nm tightening torque
  • Form-fit jaw connection
  • Coated spindle and spindle nut
  • Spindle can be extended without tools
  • Extendable to all required lengths (extensions included)
  • Retooling in seconds
  • Extensive range of accessories and jaws

Slide rail set 120 mm, with jaws
5-axis slide rail set 120 mm
  • For stable, low-vibration machining
  • 40 kN clamping force at 85 Nm tightening torque
  • Form-fit jaw connection
  • Coated spindle and spindle nut
  • Spindle can be extended without tools
  • Extendable to all required lengths (extensions included)
  • Retooling in seconds
  • Extensive range of accessories and jaws

Slide rail set 120 mm, with jaws
Article no./ATORN no.
4641011230 / 21724206
Packaging unit
1
Catalogue page
KS-1272

Technical characteristics

Anziehdrehmoment 85 N·m
Aufspannhöhe 209 mm
Backenbreite 120 mm
Breite 120 mm
Clamping width 0-270 mm
Clamping width 0-270 mm
Einspannhöhe 227 mm
Einspanntiefe 3 mm
Extensions 1 mm
Extensions 1 mm
Gewicht 40,3 kg
Grundkörperbreite 120 mm
Grundkörperlänge 300 mm
Körperbreite 160 mm
Körperhöhe 228 mm
Körperlänge 300 mm
Länge 300 mm
Length x width 300 x 120 mm
Length x width 300 x 120 mm
Nutbreite 20 mm
Schlüsselweite 12 mm
Spannkraft 40 kN
Spannschienenbreite 120 mm
Spannschienenhöhe 80 mm
Spannschienenlänge 300 mm
Spannweite max. 270 mm
Spannweite min. 0 mm
Spannweite min./max. 0-270 mm
Typ Two in One 300 mm
ASSET_MatSafetyDataSheet Download
Catalogue page Download
STEP Download
