Pull stud OTT 15° SK40, internal thread M16

Pull stud OTT 15° SK40, internal thread M16
Pull stud OTT 15° SK40, internal thread M16 Pull stud OTT 15° SK40, internal thread M16
Price:
14,90 €
prices excl. vat plus shipping costs

Stock status
in stock
External stock
available
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

Pull studs
  • For tools with a steep-angle taper in accordance with DIN 69871 and JIS B 6339 (MAS-BT)
  • All pull studs made from 16MnCr5, case hardened to HRC 58 ± 2
  • Soft thread and bore, burnished and ground
  • Pull studs with O-ring = sealed
  • Other versions available on request (machine model must be specified)

Ott ring groove, 15° with tapped head, for DIN 69871 AD shank
Pull studs
  • For tools with a steep-angle taper in accordance with DIN 69871 and JIS B 6339 (MAS-BT)
  • All pull studs made from 16MnCr5, case hardened to HRC 58 ± 2
  • Soft thread and bore, burnished and ground
  • Pull studs with O-ring = sealed
  • Other versions available on request (machine model must be specified)

Ott ring groove, 15° with tapped head, for DIN 69871 AD shank
Article no./ATORN no.
4385150040 / 20800017
Packaging unit
1
Catalogue page
KS-1168

Technical characteristics

Aussendurchmesser 21,10 mm
Bohrdurchmesser 7 mm
Coolant supply Yes
Coolant supply Yes
D 25 mm
D 21,1 mm
D 21,1 mm
D 25 mm
D1 17 mm
D1 17 mm
Design With O-ring
Design With O-ring
Drill hole 7 mm
Drill hole 7 mm
for thread M16
for thread M16
Gewindeabmessung M16
L 53 mm
L 53 mm
L1 25,1 mm
L1 25,1 mm
Suitable for tool holding device SK 40
Suitable for tool holding device SK 40
Winkel 15 °
