Surftest SJ-210 surface roughness tester

• Portable mains-independent skid system for determining surface roughness
• Separate feed allows measurements in hard-to-reach places, as well as overhead measurements
• Dust-protected, touch-sensitive control panel and integrated printer
• Extremely easy-to-use and intuitive menu navigation
• Measurement results / profiles shown clearly on a 14.5 cm (5.7”) colour display
• 16 languages
• Storage of up to 10 measurement conditions
• Statistics function and colour-coded tolerance analysis
• Customisable password protection
• Storage of measurement data on an optional SD card
• Automated calibration function / can be calibrated based on the average of up to 12 measurements
• Choice of mains or battery operation
• Profile method with single skid system
• Measurement range: X-axis feed = 16 mm, S feed = 5.6 mm
• 60° contact point with 2 µm radius / measuring force 0.75 mN
• Measuring speed: 0.25 mm/s, 0.5 mm/s, 0.75 mm/s
• Analysis parameters: Ra, Rq, Rz, Ry, Rp, Rv, Rt, R3z, Rsk, Rku, Rc, RPc, RSm, Rmax, Rz1max , S, HSC, RzJIS, Rppi, R?a, R?q, Rlr, Rmr, Rmr(c), Rdc, Rk, Rpk, Rvk, Mr1, Mr2, A1, A2, Vo, ?a, ?q, Lo, Rpm, tp, Htp, R, RX, AR, W, AW, Wx, Wte
• Cut-off length: 0.08 mm / 0.25 mm / 0.8 mm / 2.5 mm / 8 mm
• Number of individual measurement sections: 1x, 2x, 3x, 4x, 5x, 6x, 7x, 8x, 9x, 10x, unset length
• Digital filter: 2CR75 / PC75 / Gaussian
• Parameters in accordance with DIN EN ISO, VDA, JIS, ANSI and MOTIF
• Data communication: Digimatic, RS-232, SD memory card
• Supplied with roughness standard, mains adapter and 5 rolls of spare paper
