Smoothing tool SET 510 / 520

• The Zeus smoothing tool is an all-rounder in all conventional surface-smoothing operations.
• Whether on straight, conical or concave surfaces
• Planar sides can also be machined.
• Not suitable for interrupted cutting.

2nd generation

Smoothing tool holder SET 520

• Properties
  - Variably adjustable tool head
  - Supplied without smoothing tips
  - Tool for universal applications
  - Swivel range +/- 90°
  - Use up to the collar
  - The adjusting options of the tool head allow the smoothing of planar surfaces, as well as conical, convex and concave geometries.
• Recommendation
  - Polishing speed up to 200 m/min
  - Feed up to 0.2 mm/rev
  - Workpiece allowance of 0.01 mm (∼RZ 10) and 0.02 mm (∼RZ 20)
  - Cooling lubricant is recommended
• Tool holder SET 520-10 right / left including shank adapter 12x12 mm and 16x16 mm
• Tool holder SET 520-16 including shank adapter 20x20 mm and 25x25 mm
