Tangential shoulder milling cutter 90° Ø50 mm for 5 x XNMU 12

Tangential shoulder milling cutter 90° Ø50 mm for 5 x XNMU 12
Tangential shoulder milling cutter 90° Ø50 mm for 5 x XNMU 12 Tangential shoulder milling cutter 90° Ø50 mm for 5 x XNMU 12
Price:
455,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
External stock
available
Add to shopping cart
Tool Finder
Tangential

Tangential shoulder milling cutter 90°
  • Process reliability due to tangential installation position
  • 8-blade indexable insert for high efficiency
  • Efficiency due to good cutting properties
  • Cost savings thanks to reduced cycle times
  • For roughing and semi-finishing operations / steel and cast iron machining
  • Infeed depth ap max. = 10 mm
  • up to Ø 125 mm with internal cooling

Article no./ATORN no.
2625660050 / 10617475
Packaging unit
1
Catalogue page
KS-0660
Cutting values
SW-0831

Technical characteristics

ap max. 10 mm
Bore hole Ø 22 mm
Coolant supply External
Cutting data Cutting angle Information - yes
D 50 mm
Designation FMP90T X12.050AN-I
Geeignet für Wendeschneidplatten XNMU 1206..
L 40 mm
Max. tightening torque 5,2 N·m
Surface NI
Tip diameter 40 mm
Tool holding device Location bore
Werkstoff ST
Z 5 pc.
Catalogue page Download
Cutting values Download
ASSET_MatSafetyDataSheet Download
