Hydraulic expansion clamp unit Type ECOGRIP-6/ER16 Ø6 mm

Hydraulic expansion clamp unit Type ECOGRIP-6/ER16 Ø6 mm
Hydraulic expansion clamp unit Type ECOGRIP-6/ER16 Ø6 mm Hydraulic expansion clamp unit Type ECOGRIP-6/ER16 Ø6 mm
Price:
279,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
powered by ETP

Hydraulic expansion clamping unit ECOGRIP ER
  • renders ER collet systems hydraulic
  • Adjustable radial run-out
  • installed correctly, a true running accuracy of 0.003 mm is achieved. The radial run-out can be further adjusted to the desired accuracy by slightly tightening the setting screws.

For ER collet systems with external thread
powered by ETP

Hydraulic expansion clamping unit ECOGRIP ER
  • renders ER collet systems hydraulic
  • Adjustable radial run-out
  • installed correctly, a true running accuracy of 0.003 mm is achieved. The radial run-out can be further adjusted to the desired accuracy by slightly tightening the setting screws.

For ER collet systems with external thread
Article no./ATORN no.
4338041006
Packaging unit
1
Catalogue page
KS-1208

Technical characteristics

Collet type ER 16
Collet type ER 16
Connection thread M22 x 1,5
Connection thread M22 x 1,5
D1 6 mm
D1 6 mm
L 30 mm
L 30 mm
L3 14 mm
L3 14 mm
Outer diameter 34 mm
Outer diameter 34 mm
Thread M22 x 1,5
Thread M22 x 1,5
Wr. width 2,5 mm
Wr. width 2,5 mm
Catalogue page Download
