Flat drill SC 180° 3xD 3mm IC TiAlN

Flat drill SC 180° 3xD 3mm IC TiAlN
Flat drill SC 180° 3xD 3mm IC TiAlN Flat drill SC 180° 3xD 3mm IC TiAlN

We charge a material cost surcharge of 6,90% on this product.

Price
100,50 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
Solid carbide flat drill FLAT 3D with internal cooling
  • For producing flat-bottomed holes in one single operation
  • Facilitates drilling in a single operation on inclined surfaces
  • Improved drilling quality with special cutting and 4-guide chamfer geometry
  • Better self-centring

Article no./ATORN no.
1117090030 / 12040861
Packaging unit
1
Alternative items
View alternative items
Catalogue page
KS-0156
Cutting values
SW-0373

Technical characteristics

A-Maß 0,01 mm
Angle of the tip - S 180 °
Coolant supply Internal
Cutting data Cutting angle Information - yes
Cutting material Solid carbide
D 3,00 mm
D1 6 mm
DIN 6537
Eignung Edelstahl gesamt
Eignung nicht Eisen gesamt
Feed f steel < 1000 N/mm² 0,08 mm/rev
Halslänge 20,0 mm
L 62 mm
L1 14 mm
Max. drilling depth (D) 3xD
Nutzlänge 14 mm
S 180 °
Schneidendurchmesser max. 20,0 mm
Schneidendurchmesser min. 3,0 mm
Schneidendurchmesser min./max. 3,0-20,0 mm
Schnittgeschwindigkeit (Bronze kurz) Eignung
Schnittgeschwindigkeit (Bronze kurz) Vc 40 m/min
Schnittgeschwindigkeit (Bronze lang) Eignung
Schnittgeschwindigkeit (Bronze lang) Vc 30 m/min
Schnittgeschwindigkeit (Messing lang) Eignung
Schnittgeschwindigkeit (Messing lang) Vc 40 m/min
Spannutlänge 20 mm
Surface TiAlN
Tolerance of cutting edge diameter h7
Tolerance of shank diameter h6
Tool holding device HA parallel shank
Twist angle 30°
Type N
Z 2 pc.

Usage characteristics

aluminium < 8 % Si
aluminium ≥ 8 % Si
brass short
cast iron GG/GTS
cast iron GGG
hardened steel ≤ 55 HRC
stainless steel austenitic
stainless steel ferrit./martens.
steel < 1000 N/mm²
steel < 1400 N/mm²
steel < 700 N/mm²

very suitable
suitable
