Application direction milling
Lining, ramping and drilling
Cutting data
Cutting angle Information - yes
Cutting material
Solid carbide
D
3 mm
D1
6 mm
D3
2,8 mm
Design
Straight shank HA polished
Durchmesser max.
20 mm
Durchmesser min.
3 mm
Durchmesser min./max.
3-20 mm
Eignung Edelstahl gesamt
3
Eignung nicht Eisen gesamt
1
Eignung Titan/Nickel/Super gesamt
3
F x 45°
0,1 mm
Feed for grooving fz aluminium < 8 % Si
0,020 mm/tooth
Feed for side milling fz aluminium < 8 % Si
0,025 mm/tooth
fitness hartl total
3
Freistellungslänge
21 mm
fz ALU
0,022 mm
Geeignet für Werkstoffgruppe H
3
Geeignet für Werkstoffgruppe K
3
Geeignet für Werkstoffgruppe M
3
Geeignet für Werkstoffgruppe N
1
Geeignet für Werkstoffgruppe P
3
Geeignet für Werkstoffgruppe S
3
Kantenschutzfasenwinkel
45 °
L
64 mm
L1
15 mm
L2
21 mm
Spanwinkel
18 °
Tolerance of cutting edge diameter
h9
Tolerance of shank diameter
h5
Tool holding device
HA parallel shank
Twist angle
45°
Type
W
Z
3 pc.
