Standard target

• For comparing screen displays on measuring projectors
• Standard targets are reference drawings on which specific geometric shapes, e.g. circles, are drawn as fixed dimensions for the different magnifications.
• With radii
• Made from low-warp, transparent plastic, coated with a protective layer
• Geometric shapes printed on the underside
• Line widths: 0.05, 0.08, 0.10 and 0.12 mm, different for even millimetre and intermediate dimensions. Linear division line accuracy: 0.05 mm over 300 mm. Thermal expansion: 0.08 mm per 10° C
• Standard targets in other versions (e.g. for threads) available on request
