Bore gauge with three-point contact 6-8mm (0,001mm)

Sale price
239,00 €
(349,00 € catalogue price / 32% saved)
valid until: 31.01.2025
prices excl. vat plus shipping costs

Stock status
in stock

Ordered by 18:00 - delivered tomorrow.

Add service

*
*
Inside micrometers with three-point contacts
  • For measuring through-holes and blind holes
  • Large measurement depths due to extension
  • Reading and operating parts matt chrome-plated
  • Measuring spindle fully hardened and ground
  • Ratchet coupling for repeatable measuring force
  • Self-centring measuring head with three laterally extending measuring probes
  • Carbide-tipped from a measurement range of 12 mm
  • Clearance a for 6 – 12 mm = 1.4 mm, 12 – 100 mm = 0.5 mm
  • Scale division up to size 0012 = 0.001 mm, from size 0016 = 0.005 mm
  • Calibration including ring gauges, reduced testing
  • Supplied in a sturdy transport case including ring gauge and extension

Individual
Inside micrometers with three-point contacts
  • For measuring through-holes and blind holes
  • Large measurement depths due to extension
  • Reading and operating parts matt chrome-plated
  • Measuring spindle fully hardened and ground
  • Ratchet coupling for repeatable measuring force
  • Self-centring measuring head with three laterally extending measuring probes
  • Carbide-tipped from a measurement range of 12 mm
  • Clearance a for 6 – 12 mm = 1.4 mm, 12 – 100 mm = 0.5 mm
  • Scale division up to size 0012 = 0.001 mm, from size 0016 = 0.005 mm
  • Calibration including ring gauges, reduced testing
  • Supplied in a sturdy transport case including ring gauge and extension

Individual
Article no./ATORN no.
5077030008
Packaging unit
1
Catalogue page

Technical characteristics

Adjusting ring diameter 6 mm
Adjusting ring diameter 6 mm
DIN 863/4
DIN 863/4
Display Analogue
Error limit 4 µm
Error limit 4 µm
Included in delivery Sturdy box
Included in delivery Sturdy box
Measurement range 6 - 8 mm
Measurement range 6 - 8 mm
Measuring depth 55 mm
Measuring depth 55 mm
Measuring depth max. 155 mm
Measuring depth max. 155 mm
Measuring spindle increments 0,5 mm
Measuring spindle increments 0,5 mm
