Boring bar A16M SVJC-R-11 setting angle 52°, for turning inserts VC..1103.., IC

Boring bar A16M SVJC-R-11 setting angle 52°, for turning inserts VC..1103.., IC
Boring bar A16M SVJC-R-11 setting angle 52°, for turning inserts VC..1103.., IC Boring bar A16M SVJC-R-11 setting angle 52°, for turning inserts VC..1103.., IC
Price:
199,50 €
prices excl. vat plus shipping costs

Stock status
in stock
External stock
available
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

Boring bar, positive SVJC
  • SVJC R/L 52°
  • Setting angle 52°, for positive 7º rhombic indexable inserts, 35º point angle
  • Internal coolant supply
  • Use: Longitudinal and copy turning, ball turning

Article no./ATORN no.
3215291116 / 11111028
Packaging unit
1
Catalogue page
KS-0939

Technical characteristics

Anstellwinkel 52 °
Coolant supply Internal
D min. 22 mm
D1 16 mm
Design Right
DIN 8024
F 2 mm
Freiwinkel 7 °
ISO designation A 16 M SVJC R/L 11
Klemmsystem S
L 150 mm
L2 31,4 mm
Schaftausführung A
Schneidenhöhe 7,5 mm
Schneidenlänge 11 mm
Spannflächenhöhe 15 mm
suitable indexable inserts VC.. 1103..
Wendeschneidplattenform ISO V
Wendeschneidplattenwinkel 35 °
Werkstoff ST
