Boring bar A25R PTFN-L-16 setting angle 90°, for turning inserts TNM.1604.., IC

Boring bar A25R PTFN-L-16 setting angle 90°, for turning inserts TNM.1604.., IC
Boring bar A25R PTFN-L-16 setting angle 90°, for turning inserts TNM.1604.., IC Boring bar A25R PTFN-L-16 setting angle 90°, for turning inserts TNM.1604.., IC
Price:
252,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
Boring bar, negative PTFN
  • PTFN R/L 90°
  • Setting angle 90°, for negative 0º triangular indexable inserts, 90º point angle
  • Use: Longitudinal turning

With internal cooling
  • one clamping surface from above

Article no./ATORN no.
3215110125 / 11220210
Packaging unit
1
Catalogue page
KS-0928

Technical characteristics

Anstellwinkel 90 °
Bohrungsdurchmesser min. 32 mm
D min. 32 mm
D1 25 mm
Design Left
F 17 mm
Freistellungslänge 40 mm
Freiwinkel 0 °
H 11,5 mm
H 23 mm
ISO designation A 25 R PTFN R/L 16
Klemmsystem P
L 200 mm
Schaftausführung A
Schneidenlänge 16 mm
suitable indexable inserts TN.. 1604..
Wendeschneidplattenform ISO T
Wendeschneidplattenwinkel 60 °
Werkstoff ST
