Drilling/die sinking cutter 90° 32x130mm, shank 32mm, for 3 II AP..1604

Drilling/die sinking cutter 90° 32x130mm, shank 32mm, for 3 II AP..1604
Drilling/die sinking cutter 90° 32x130mm, shank 32mm, for 3 II AP..1604 Drilling/die sinking cutter 90° 32x130mm, shank 32mm, for 3 II AP..1604 Drilling/die sinking cutter 90° 32x130mm, shank 32mm, for 3 II AP..1604
Price:
395,00 €
prices excl. vat plus shipping costs

Stock status
in stock
External stock
available
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

90° drilling/die sinking cutter
  • For ISO milling inserts, type AP.. 1604
  • Internal coolant supply
  • With Weldon shank
  • High cutting capacity
  • Reliable chip flow even when drilling due to positive indexable insert geometry
  • Supplied with clamping screws and wrench

Short
Article no./ATORN no.
2625150004 / 11117232
Packaging unit
1
Catalogue page
KS-0650

Technical characteristics

Anzahl Wendeplatten 3 pc.
ap max. 30 mm
Application Drill cutting
Coolant supply Internal
D 32 mm
D1 32 mm
Freistellungslänge 50 mm
Geeignet für Wendeschneidplatten AP.. 1604..
L 130 mm
L1 50 mm
Max. tightening torque 4,01 N·m
Oberfläche NI
Passende Wendeschneidplatten-Nr. 27
Tool holding device HB parallel shank
Z 3 pc.
