Solid carbide torus cutter 2mm R0,5mm L=50mm Z=2 HA, TiAlN-Ultra

Solid carbide torus cutter 2mm R0,5mm L=50mm Z=2 HA, TiAlN-Ultra
Solid carbide torus cutter 2mm R0,5mm L=50mm Z=2 HA, TiAlN-Ultra Solid carbide torus cutter 2mm R0,5mm L=50mm Z=2 HA, TiAlN-Ultra Solid carbide torus cutter 2mm R0,5mm L=50mm Z=2 HA, TiAlN-Ultra
Price:
65,10 €
prices excl. vat plus shipping costs

Stock status
in stock
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

Torus milling cutter
  • With clearance
  • First-rate chip removal due to extremely smooth surface
  • Cutting material: ultra-fine grain solid carbide, TiAlN-Ultra-coated

Article no./ATORN no.
2540700204 / 10911716
Packaging unit
1
Catalogue page

Technical characteristics

Coating TiAlN
Cutting data Cutting angle Information - yes
Cutting material Solid carbide
D 2,0 mm
D1 6,0 mm
D3 1,8 mm
Feed for side milling fz steel < 1400 mm² 0,014 mm/tooth
Jaw quantity 2 cutting edges
L 50 mm
L1 2 mm
L2 7 mm
Milling application Side Ramp Plunge
Milling technology HSC
R 0,5 mm
Shank Straight, DIN 6535 HA
Spiral angle 20° RH helix angle

Usage characteristics

cast iron GG/GTS
cast iron GGG
hardened steel < 60 HRc
hardened steel ≤ 55 HRC
hardened steel ≤ 65 HRC
steel < 1000 N/mm²
steel < 1400 N/mm²
steel < 700 N/mm²

very suitable
suitable
DXF Download
