Disc milling cutter HSS-E DIN1834A 63x1,6x22mm 28 ridges, narrow

Disc milling cutter HSS-E DIN1834A 63x1,6x22mm 28 ridges, narrow
Disc milling cutter HSS-E DIN1834A 63x1,6x22mm 28 ridges, narrow Disc milling cutter HSS-E DIN1834A 63x1,6x22mm 28 ridges, narrow
Price
109,50 €
prices excl. vat plus shipping costs

Stock status
in stock
Add to shopping cart
Tool Finder

Ordered by 18:00 - delivered tomorrow.

Disc milling cutters
  • Narrow version
  • 3 cutting edges
  • Type N, cross-cut toothing
  • Bore with longitudinal groove in accordance with DIN 138
  • Smooth cut thanks to helical toothing
  • Optimum chip removal with spacious chip chambers
  • Milling cutters are self-freeing to prevent jamming

Article no./ATORN no.
2101050001
Packaging unit
1
Catalogue page
KS-0578
Cutting values
SW-0728

Technical characteristics

Bore hole Ø 22 mm
Cutting data Cutting angle Information - no
Cutting material HSSE
D 63 mm
DIN 1834
Number of teeth 28 pc.
Type N
W 1,6 mm

Usage characteristics

aluminium < 8 % Si
aluminium ≥ 8 % Si
brass short
cast iron GG/GTS
cast iron GGG
stainless steel austenitic
stainless steel duplex
stainless steel ferrit./martens.
steel < 1000 N/mm²
steel < 1400 N/mm²
steel < 700 N/mm²

very suitable
suitable
