MHD high-precision boring head TRM16/16 MHD'16 Ø18-23mm (insert holder SF..16)

MHD high-precision boring head TRM16/16 MHD'16 Ø18-23mm (insert holder SF..16)
MHD high-precision boring head TRM16/16 MHD'16 Ø18-23mm (insert holder SF..16) MHD high-precision boring head TRM16/16 MHD'16 Ø18-23mm (insert holder SF..16)
Price:
529,00 €
prices excl. vat plus shipping costs

Stock status
in stock
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

MHD micrometric boring bar system
  • TRM boring heads and micrometric boring bars ensure a tolerance of IT6 with an optimum surface finish quality.
  • Settings with a radial correction of 1µm can easily be read off the Vernier scale and executed directly on the machine.

TRM high-precision boring head, Ø 18 - 63
MHD micrometric boring bar system
  • TRM boring heads and micrometric boring bars ensure a tolerance of IT6 with an optimum surface finish quality.
  • Settings with a radial correction of 1μm can easily be read off the Vernier scale and executed directly on the machine.

TRM high-precision boring head, Ø 18 - 63
Article no./ATORN no.
3728101616
Vendor Article no.
455001600341
Packaging unit
1
Catalogue page
KS-0344

Technical characteristics

D 18 - 23 mm
D 16
D min./max. 18 - 23 mm
L 34 mm
L 34 mm
L7 1 mm
MHD'd1 16
SF.. 16
suitable for jaw width SF16
Type TRM 16/16
Type TRM 16/16
Weight 0,05 kg
Weight 0,05 kg
Catalogue page Download
Cutting values Download
Cutting values Download
Catalogue page Download
