MHD twin-cutter boring bar TS 16/16 MHD'16 Ø18-22mm (insert holder S... 16)

MHD twin-cutter boring bar TS 16/16 MHD'16 Ø18-22mm (insert holder S... 16)
MHD twin-cutter boring bar TS 16/16 MHD'16 Ø18-22mm (insert holder S... 16) MHD twin-cutter boring bar TS 16/16 MHD'16 Ø18-22mm (insert holder S... 16)
Price:
193,50 €
prices excl. vat plus shipping costs

Stock status
in stock
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

MHD two-flute boring bars TS
  • Rigid design, spline surfaces between the insert holders
  • Constant distance between the insert holder clamping screw and the cutting edge
  • Note: when using only one insert holder, protective plug PT should be fitted (optional)
  • Chamfer rings (AS) available on request

TS Ø 18 - 200
MHD two-flute boring bars TS
  • Rigid design, spline surfaces between the insert holders
  • Constant distance between the insert holder clamping screw and the cutting edge
  • Note: when using only one insert holder, protective plug PT should be fitted (optional)
  • Chamfer rings (AS) available on request

TS Ø 18 - 200
Article no./ATORN no.
3726031616
Vendor Article no.
455501600340
Packaging unit
1
Catalogue page
KS-0341

Technical characteristics

D 18- 22 mm
D 16
D min./max. 18 - 22 mm
D2 16 mm
Drill diameter 16 mm
for exchangeable CC plates yes
L 34 mm
L 34 mm
L1 - mm
L1 - mm
MHD'd1 16
S... S...16
suitable for jaw width S...16
suitable indexable inserts CC
Type TS 16/16
Type TS 16/16
Weight 0,05 kg
Weight 0,05 kg
