Threading die HSS EN22568 UNF no.4-48 thread/inch

Threading die HSS EN22568 UNF no.4-48 thread/inch
Threading die HSS EN22568 UNF no.4-48 thread/inch Threading die HSS EN22568 UNF no.4-48 thread/inch
Price:
63,20 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
Threading dies
  • For UNF (American unified national standard fine-pitch) threads
  • Closed, pre-slotted shape
  • From no. 5 with two-sided spiral point for clean and easy chip removal in the cutting direction
  • Cutting material: HSS
  • Note: For cutting true-to-gauge threads in tolerance zone 2A
  • * Without spiral point

Threading dies
  • For UNF (American unified national standard fine-pitch) threads
  • Closed, pre-slotted shape
  • From no. 5 with two-sided spiral point for clean and easy chip removal in the cutting direction
  • Cutting material: HSS
  • Note: For cutting true-to-gauge threads in tolerance zone 2A
  • * Without spiral point

Article no./ATORN no.
1360500005 / 11190171
Packaging unit
1
Catalogue page
KS-0301
Cutting values
SW-0399

Technical characteristics

Coolant supply External
Coolant supply External
Cutting data Cutting angle Information - yes
Cutting data Cutting angle Information - yes
Cutting material HSS
Cutting material HSS
D UNF no. 4*
D UNF no. 4*
DIN 22568
DIN 22568
Eignung Edelstahl gesamt 3
Eignung nicht Eisen gesamt 2
Eignung Titan/Nickel/Super gesamt 3
EN-Norm 22568
fitness hartl total 3
Height 5 mm
Height 5 mm
N 4
N 4
Nominal diameter in inches 4 in
Outer diameter 16 mm
Outer diameter 16 mm
Passend für Gewinde UNF Nr,4-UNF 3/4 Zoll
Pitch 48
Pitch 48
Thread UNF
Thread UNF
Thread angle 60 °
Thread angle 60 °
Thread type x nominal diameter in inches UNF 4 in
Tolerance of dies 2A
Tolerance of dies 2A

Usage characteristics

aluminium < 8 % Si
aluminium < 8 % Si
bronze short
bronze short
D 4 in
D UNF 4 in
D 4 in
D UNF 4 in
plastic
plastic
steel < 700 N/mm²
steel < 700 N/mm²

very suitable
suitable
Catalogue page Download
Cutting values Download
Catalogue page Download
Cutting values Download
ASSET_MatSafetyDataSheet Download
