Threading die HSS-E EN22568 M5x0,5 6g

Threading die HSS-E EN22568 M5x0,5 6g
Threading die HSS-E EN22568 M5x0,5 6g Threading die HSS-E EN22568 M5x0,5 6g
Price:
67,30 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
External stock
available
Add to shopping cart
Tool Finder
Threading dies
  • For metric ISO fine threads DIN 13
  • Closed, pre-slotted shape
  • With two-sided spiral point for clean and easy chip removal in the cutting direction
  • Tolerance field 6 g
  • Cutting material HSS-E (lapped and nitrided)

Threading dies
  • For metric ISO fine threads DIN 13
  • Closed, pre-slotted shape
  • With two-sided spiral point for clean and easy chip removal in the cutting direction
  • Tolerance field 6 g
  • Cutting material HSS-E (lapped and nitrided)

Article no./ATORN no.
1360200010 / 11190143
Packaging unit
1
Catalogue page
KS-0300
Cutting values
SW-0399

Technical characteristics

Coolant supply External
Coolant supply External
Cutting data Cutting angle Information - yes
Cutting data Cutting angle Information - yes
Cutting material HSSE
Cutting material HSSE
D MF5
D MF5
DIN 22568
DIN 22568
Eignung Edelstahl gesamt 1
Eignung nicht Eisen gesamt 3
Eignung Titan/Nickel/Super gesamt 1
EN-Norm 22568
fitness hartl total 3
Height 5 mm
Height 5 mm
N 4
N 4
Nenndurchmesser 5 mm
Outer diameter 20 mm
Outer diameter 20 mm
Passend für Gewinde MF5-MF30
Pitch 0,5 mm
Pitch 0,5 mm
Thread MF
Thread MF
Thread angle 60 °
Thread angle 60 °
Tolerance of dies 6g
Tolerance of dies 6g

Usage characteristics

aluminium ≥ 8 % Si
aluminium ≥ 8 % Si
bronze long
bronze long
D M 5 mm
D M 5 mm
stainless steel austenitic
stainless steel austenitic
stainless steel ferrit./martens.
stainless steel ferrit./martens.
steel < 1000 N/mm²
steel < 1000 N/mm²
steel < 1400 N/mm²
steel < 1400 N/mm²
superalloys Fe/NiCo based < 30 HRC
superalloys Fe/NiCo based < 30 HRC
superalloys Fe/NiCo based ≥ 30 HRc
superalloys Fe/NiCo based ≥ 30 HRc
titanium alloys
titanium alloys

very suitable
suitable
