Threading die HSS EN22568 M3x0,35 6g

Threading die HSS EN22568 M3x0,35 6g
Threading die HSS EN22568 M3x0,35 6g Threading die HSS EN22568 M3x0,35 6g
Price
62,30 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder
Threading dies
  • For ISO fine-pitch metric thread, DIN 13
  • Closed, pre-slotted shape
  • From M3 with two-sided spiral point for clean and easy chip removal in the cutting direction
  • Tolerance zone 6g, M2 x 0.25 = 6h, without spiral point
  • Cutting material: HSS
  • * Without spiral point

Article no./ATORN no.
1360150006 / 11190076
Packaging unit
1
Catalogue page
KS-0301
Cutting values
KS-0301

Technical characteristics

Coolant supply External
Cutting data Cutting angle Information - yes
Cutting material HSS
D M 3 mm
DIN 22568
Eignung Edelstahl gesamt 3
Eignung nicht Eisen gesamt 2
Eignung Titan/Nickel/Super gesamt 3
EN-Norm 22568
External Ø 20 mm
fitness hartl total 3
Gewindeart x Nenndurchmesser MF3
Height 5 mm
N 4
Nenndurchmesser 3 mm
Outer diameter 20 mm
Passend für Gewinde MF2-MF63
Pitch 0,35 mm
Thread MF
Thread angle 60 °
Tolerance of dies 6g

Usage characteristics

aluminium ≥ 8 % Si
bronze long
plastic
steel < 700 N/mm²

very suitable
suitable
