Threading die HSS EN22568 M3 6g LH

Threading die HSS EN22568 M3 6g LH
Threading die HSS EN22568 M3 6g LH Threading die HSS EN22568 M3 6g LH
Special offer:
26,20 €
(62,40 € catalogue price / 58% saved)
prices excl. vat plus shipping costs

Stock status
Only 0 pieces left!
Add to shopping cart
Tool Finder
Left-hand threading die
  • For ISO left-hand metric thread, DIN 13
  • Closed, pre-slotted shape
  • From M3 with two-sided spiral point for clean and easy chip removal in the cutting direction
  • Tolerance zone 6g
  • Cutting material: HSS

Left-hand threading die
  • For ISO left-hand metric thread, DIN 13
  • Closed, pre-slotted shape
  • From M3 with two-sided spiral point for clean and easy chip removal in the cutting direction
  • Tolerance zone 6g
  • Cutting material: HSS

Article no./ATORN no.
1360100030 / 11190034
Packaging unit
1
Catalogue page
KS-0297
Cutting values
SW-0399

Technical characteristics

Coolant supply External
Coolant supply External
Cutting data Cutting angle Information - yes
Cutting data Cutting angle Information - yes
Cutting material HSS
Cutting material HSS
D M 3-LH mm
D M 3-LH mm
DIN 22568
DIN 22568
Eignung Edelstahl gesamt 3
Eignung nicht Eisen gesamt 2
Eignung Titan/Nickel/Super gesamt 3
EN-Norm 22568
fitness hartl total 3
Gewindeart x Nenndurchmesser M3
Height 5 mm
Height 5 mm
N 4
N 4
Nenndurchmesser 3 mm
Outer diameter 20 mm
Outer diameter 20 mm
Passend für Gewinde M3 L-M24 L
Pitch 0,5 mm
Pitch 0,5 mm
Thread M-L
Thread M-L
Thread angle 60 °
Thread angle 60 °
Tolerance of dies 6g
Tolerance of dies 6g

Usage characteristics

aluminium < 8 % Si
aluminium < 8 % Si
brass short
brass short
bronze long
bronze long
plastic
plastic
stainless steel austenitic
stainless steel austenitic
stainless steel ferrit./martens.
stainless steel ferrit./martens.
steel < 1000 N/mm²
steel < 1000 N/mm²
steel < 700 N/mm²
steel < 700 N/mm²

very suitable
suitable
