Thread limit plug gauge DIN13 M3 TiN

Price
118,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
External stock
available

Add service

*
*
Thread gauges for metric thread, TiN
  • Wear-resistant steel, optionally TiN-coated, surface hardness approx. 2500 HV, meaning:
    Improved corrosion resistance
    Up to 10x greater wear resistance
    Extendable calibration intervals
  • Precision-ground thread
  • Tolerances and deviations in accordance with DIN ISO 1502

Thread limit plug gauges for right-hand ISO metric thread, DIN 13
  • For Go/No-Go inspection of nut threads
  • Go end coated
  • Tolerance class 6H

Thread gauges for metric thread, TiN
  • Wear-resistant steel, optionally TiN-coated, surface hardness approx. 2500 HV, meaning:
    Improved corrosion resistance
    Up to 10x greater wear resistance
    Extendable calibration intervals
  • Precision-ground thread
  • Tolerances and deviations in accordance with DIN ISO 1502

Thread limit plug gauges for right-hand ISO metric thread, DIN 13
  • For Go/No-Go inspection of nut threads
  • Go end coated
  • Tolerance class 6H

Article no./ATORN no.
5410040030 / 31730103
Packaging unit
1
Catalogue page

Technical characteristics

Coating TiN
Coating TiN
D M3 x 0,5 mm
D M3 x 0,5 mm
DIN 2280
Gewindeart x Nenndurchmesser x Steigung M3 x 0,5
Kalibriergruppe AA
Nenndurchmesser 3 mm
Nennmaß 3 mm
Steigung 0,5 mm
Thread type M
Toleranzklasse 6H
Werkstoff TiN
