Twist drill HSS-E 5xD DIN338VA 135° 2-8mm 3-sided clamping surface (6-piece)

Twist drill HSS-E 5xD DIN338VA 135° 2-8mm 3-sided clamping surface (6-piece)
Twist drill HSS-E 5xD DIN338VA 135° 2-8mm 3-sided clamping surface (6-piece)
Price:
41,00 €
prices excl. vat plus shipping costs

Stock status
in stock
External stock
available
Add to shopping cart
Tool Finder

Ordered by 19:30 - delivered tomorrow.

Twist drill bit sets, with 3 surface shank
  • 3-facet grinding on shank (from Ø 4 mm) for optimum transfer of force and secure hold in the drill chuck, no possibility of slippage
  • Low force application when opening and closing in the drill chuck
  • Special surface treatment in conjunction with relief grinding for maximum lubricant adhesion and for fast, reliable chip removal
  • Designed especially for use on portable drilling machines

Article no./ATORN no.
1010760001 / 11230162
Packaging unit
1
Catalogue page
KS-0088
Cutting values
SW-0359

Technical characteristics

Angle of the tip - S 135 °
Coating uncoated
Contents 2.0 - 8.0 mm
Coolant supply External
Cutting data Cutting angle Information - yes
Cutting material HSSE
D 2,0 - 8,0 mm
DIN 338
Drallwinkel 38°
Eignung Edelstahl gesamt 1
Eignung nicht Eisen gesamt 1
Eignung Titan/Nickel/Super gesamt 2
fitness hartl total 3
Max. drilling depth (D) 5xD
Number of pieces 6 pc.
Schneidendurchmesser max. 8 mm
Schneidendurchmesser min. 2 mm
Schneidendurchmesser min./max. 2-8 mm
Section shape Split point
Steigung der Bohrerdurchmesser 1 mm
Surface Uncoated
Tolerance of cutting edge diameter h8
Tool holding device HA parallel shank
Type VA
Z 2 pc.

Usage characteristics

aluminium < 8 % Si
aluminium ≥ 8 % Si
brass long
brass short
bronze long
bronze short
cast iron GGG
graphite
plastic
stainless steel austenitic
stainless steel ferrit./martens.
steel < 1000 N/mm²
steel < 1400 N/mm²
steel < 700 N/mm²
superalloys Fe/NiCo based < 30 HRC
superalloys Fe/NiCo based ≥ 30 HRc
titanium alloys

very suitable
suitable
