Digital 3-pt int. probe 7-14mm (0.002mm) IP67, meas. depth 34mm, C ball Ø0.6mm

Digital 3-pt int. probe 7-14mm (0.002mm) IP67, meas. depth 34mm, C ball Ø0.6mm
Digital 3-pt int. probe 7-14mm (0.002mm) IP67, meas. depth 34mm, C ball Ø0.6mm Digital 3-pt int. probe 7-14mm (0.002mm) IP67, meas. depth 34mm, C ball Ø0.6mm Digital 3-pt int. probe 7-14mm (0.002mm) IP67, meas. depth 34mm, C ball Ø0.6mm
Price:
540,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
Add to shopping cart
Tool Finder

Add service

*
*
Digital internal fast display calliper with 3-point contact IP67
  • 3-point contact improves centring for a faster process, reliable measurement and accurate results
  • Adjustable increments: 0.001 / 0.002 / 0.005 / 0.01 / 0.02 / 0.05 mm
  • Enhanced analogue/digital display with a display area of 250°
  • Optional Bluetooth interface (up to 8 devices at once)
  • Optional USB and DIGIMATIC interface
  • Memory can store up to 100 measurement values
  • Functions: Control lever, measurement program selection, start menu and functions, data transfer, ON/OFF, 0-PRESET
  • Supplied with 2x AAA batteries, no. 548079 4003
  • Special accessories: Digimatic interface adapter no. 524002 0005 plus Digimatic cable Type E, no. 563100 0041 (1 m), no. 563100 0042 (2 m), USB cable Type E-USB no. 563110 0005, Bluetooth interface adapter no. 524002 0015

Digital internal fast display calliper with 3-point contact IP67
  • 3-point contact improves centring for a faster process, reliable measurement and accurate results
  • Adjustable increments: 0.001 / 0.002 / 0.005 / 0.01 / 0.02 / 0.05 mm
  • Enhanced analogue/digital display with a display area of 250°
  • Optional Bluetooth interface (up to 8 devices at once)
  • Optional USB and DIGIMATIC interface
  • Memory can store up to 100 measurement values
  • Functions: Control lever, measurement program selection, start menu and functions, data transfer, ON/OFF, 0-PRESET
  • Supplied with 2x AAA batteries, no. 548079 4003
  • Special accessories: Digimatic interface adapter no. 524002 0005 plus Digimatic cable Type E, no. 563100 0041 (1 m), no. 563100 0042 (2 m), USB cable Type E-USB no. 563110 0005, Bluetooth interface adapter no. 524002 0015

Article no./ATORN no.
5210171014
Vendor Article no.
L107P3
Packaging unit
1
Catalogue page
KS-1416

Technical characteristics

Data transmission type DIGIMATIC/USB
DIN Company standard
Error limit 0,01 mm
Error limit 0,01 mm
Groove depth A max. 2,2 mm
Groove width 0,8 mm
Included in delivery Manufacturer’s test certificate
Measurement range 7-14 mm
Measurement range 7-14 mm
Measuring depth 34 mm
Measuring depth 34 mm
Measuring probe Carbide ball 0.6 mm
Measuring probe Carbide ball 0.6 mm
Measuring unit Unit mm/inch
Output data format USB
Packaging / Shipment Manufacturer’s test certificate
Protection type IP 67
Protection type IP 67
Reading 0,002 mm
Standard constructional dimensions DIN Non-DIN
With mm / inch switching Yes
