Cutting insert RS08.0150.02 carb. precis. turning int. b=1.5 mm Dmin=8 mm AL41F

Cutting insert RS08.0150.02 carb. precis. turning int. b=1.5 mm Dmin=8 mm AL41F
Cutting insert RS08.0150.02 carb. precis. turning int. b=1.5 mm Dmin=8 mm AL41F Cutting insert RS08.0150.02 carb. precis. turning int. b=1.5 mm Dmin=8 mm AL41F
Price
20,90 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
External stock
available
Add to shopping cart
Tool Finder
Carbide indexable cutting inserts MINI-CUT
NC precision turning (internal)
  • Carbide AL41F TiAIN-coated
  • Ap max. = 0.2 mm (maximum cutting depth)
  • ST = tool holder front face
  • R = right-hand, as shown
  • L = left-hand, mirror image

Article no./ATORN no.
3050250001
Vendor Article no.
RS08.150.02/AL41F
Packaging unit
1
Catalogue page
KS-1024
Cutting values
SW-1105

Technical characteristics

Cutting data Cutting angle Information - yes
D 6,0 mm
D min. 8 mm
Design Right
Designation R/LS08.150.02
F 4,8 mm
S 3,3 mm
suitable for holder 608
t max. 1,0 mm
W 1,5 mm
Catalogue page Download
Cutting values Download
