Neigungsmessgerät digital PRO3600

Neigungsmessgerät digital PRO3600
Neigungsmessgerät digital PRO3600
Price:
899,00 €
prices excl. vat plus shipping costs

Stock status
subsequent delivery
External stock
available
Add to shopping cart
Tool Finder

Add service

*
*
Inclinometer
  • For measuring planarity, perpendicularity and angularity
  • Digital display
  • Precision supporting surface in an aluminium frame with V on one side
  • Display flips automatically when rotated through 180°
  • Accuracy: Factory standard
    Power supply: 9 V battery
    Operating temperature: -5°C to 50°C
    Dimensions: 153 x 49 x 31 mm
    Weight: 300 g
  • Supplied in a case with 6LR61 battery, no. 548079 4022

Inclinometer
  • For measuring planarity, perpendicularity and angularity
  • Digital display
  • Precision supporting surface in an aluminium frame with V on one side
  • Display flips automatically when rotated through 180°
  • Accuracy: Factory standard
    Power supply: 9 V battery
    Operating temperature: -5°C to 50°C
    Dimensions: 153 x 49 x 31 mm
    Weight: 300 g
  • Supplied in a case with 6LR61 battery, no. 548079 4022

Article no./ATORN no.
5565302002
Vendor Article no.
950-318
Packaging unit
1
Catalogue page

Technical characteristics

Designation Neigungsmessgerät digital PRO3600 Messbereich=4x90°
Error limit 0,05° (0° bis 10° ) 0,2° (10° bis 80° ) 0,1° (80° bis 90°) mm
Error limit 0,05° (0° bis 10° ) 0,2° (10° bis 80° ) 0,1° (80° bis 90°) mm
Measurement range 360° (4 x 90°)
model Pro 3600
Numerical intervals/sensitivity 0,01° (0° bis 9,99°) 0,1° (10° bis 90°)
Numerical intervals/sensitivity 0,01° (0° bis 9,99°) 0,1° (10° bis 90°)
Repetition precision ±0,05° µm
Repetition precision +/- 0,5° µm
